Rating

Extruder Geared Box

EXTRUDER GEAR BOX RATING CHART (Hardden & Ground)

Nominal Ratio	Nominal speed ratio		Size of Gear Unit
			80	90	100	110	125	140	160	180	200
			Nominal gear box rating PN (KW)
IN	n1	n2
6.3	1500 1000 750	238 159 119	12	20	24	32	45	63	95	131	185
			7	13	17	22	31	42	64	90	131
			6	9	13.5	16	23	32	49	67	99
10	1500 1000 750	150 100 75	6.5	11	16.2	23	31	45	67	99	135
			5	6	11	15	22	30	44	61	86
			4	5	8	12	16	23	33	45	72
14.5	1500 1000 750	103 69 52	5	6	10	15	23	32	43	61	90
			3.7	4.5	6.3	10	15	22	29	41	63
			2.5	3	4.5	8	12	16	22	32	47
16	1500 1000 750	94 63 47			9	14	20	27	39	54	81
					6.3	9	13	18	26	36	56
					4.5	7	10	14	20	29	42
18	1500 1000 750	83 56 42			8	11	17	26	33	50	68
					5	7	11	17	23	35	46
					4.5	5	9	13	17	27	36

NOTE :	1. VERIFY THERMAL POWER RATING FOR RATINGS SHOWN UNDER SHADED AREA.
	2. MINIMUM SERVICE FACTOR TO BE SELECTED 1.5 ON MOTOR POWER.
	3. NOMINAL RATIO - N1/N2.
	4. RATED TRANSMISSIBLE POWER (KW).

Helical Geared Motor

MOTOR
KW/HP

OUTPUT
RPM

GEARED MOTOR
FRAME SIZE

SERVICE
FACTOR

OUTPUT
TORQUE (Kgm)

O.12 / 0.16

18
20
25
31
39
45
66
75
96
118
161
186
256
272
355

PSH-22/63F/4
PSH-22/63F/4
PSH-22/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4

2.3
2.5
3.1
1.3
1.6
2.0
2.5
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0

5.7
5.1
4.1
3.3
2.6
2.2
1.5
1.3
1.0
0.8
0.6
0.5
0.4
0.3
0.2

0.18 / 0.25

18
20
25
31
39
48
66
75
96
118
161
186
256
272
285

PSH-22/63F/4
PSH-22/63F/4
PSH-22/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4
PSH-1/63F/4

1.6
1.8
2.2
1.0
1.1
1.4
2.0
2.5
3.0
3.0
3.0
3.0
3.0
3.0
3.0

8.9
8.0
6.4
5.1
4.1
3.3
2.4
2.1
1.6
1.3
1.0
0.8
0.6
0.5
0.5

0.25 / 0.33

18
20
25
31
40
58
66
75
96
118
161
186
256
272
285

PSH-22/71F/4
PSH-22/71F/4
PSH-22/71F/4
PSH-2/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4

1.2
1.3
1.7
1.4
1.0
1.4
1.4
1.5
2.0
2.7
3.8
4.5
4.5
4.5
4.5

11.8
10.6
8.5
6.8
5.3
3.6
3.2
2.8
2.2
1.8
1.3
1.1
0.8
0.7
0.7

0.37 / 0.5

18
20
25
30
32
39
66
75
96
118
161
186
256
266
273

PSH-33/71F/4
PSH-33/71F/4
PSH-22/71F/4
PSH-2/71F/4
PSH-2/71F/4
PSH-2/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4
PSH-1/71F/4

1.7
1.5
1.0
1.0
1.0
1.1
1.0
1.1
1.5
1.8
2.5
2.0
4.0
4.0
4.0

17.8
16.1
12.8
10.7
10.0
8.2
4.8
4.2
3.3
2.7
2.0
1.7
1.2
1.2
1.1

0.55 / 0.75

18
20
24
32
40
50
63
80
100
125
146
200
250
315
355

PSH-33/80F/4
PSH-33/80F/4
PSH-33/80F/4
PSH-3/80F/4
PSH-3/80F/4
PSH-2/80F/4
PSH-2/80F/4
PSH-2/80F/4
PSH-1/80F/4
PSH-1/80F/4
PSH-1/80F/4
PSH-1/80F/4
PSH-1/80F/4
PSH-1/80F/4
PSH-1/80F/4

1.0
1.2
1.5
1.2
1.3
1.0
1.3
1.7
1.0
1.3
1.5
2.0
2.6
3.3
3.6

26.8
24.1
20.1
15.1
12.0
9.6
7.6
6.0
4.8
3.8
3.3
2.4
1.9
1.5
1.3

0.75 / 1.0

18
20
25
36
39
55
78
82
100
127
175
200
262
278
355

PSH-43/80F/4
PSH-43/80F/4
PSH-33/80F/4
PSH-33/80F/4
PSH-3/80F/4
PSH-3/80F/4
PSH-2/80F/4
PSH-2/80F/4
PSH-2/80F/4
PSH-2/80F/4
PSH-2/80F/4
PSH-2/80F/4
PSH-1/80F/4
PSH-1/80F/4
PSH-1/80F/4

1.1
1.25
1.1
1.5
1.0
1.5
1.2
1.3
1.6
1.9
2.5
2.8
1.8
2.0
2.5

35.7
32..2
25.7
17.8
16.5
11.7
8.2
7.8
6.4
5.0
3.6
3.2
2.4
2.3
1.8

1.1/ 1.5

18
20
25
30
42
54
76
92
127
150
197
260
290
355

PSH-43B/90S/4
PSH-43B/90S/4
PSH-43/90S/4
PSH-43/90S/4
PSH-33/90S/4
PSH-33/90S/4
PSH-3/90S4
PSH-3/90S/4
PSH-2/90S/4
PSH-2/90S/4
PSH-2/90S/4
PSH-2/90S/4
PSH-2/90S/4
PSH-2/90S/4

1.0
1.2
1.0
1.2
1.3
1.6
1.4
1.0
1.25
1.4
1.9
1.5
1.6
2.0

53.6
48.3
38.7
32.2
23.0
17.8
12.7
10.5
7.6
6.4
4.9
3.7
3.3
2.7

1.5 / 2.0

18
20
25
32
40
54
65
76
97
127
141
195
260
290
355

PSH-53/90L/4
PSH-53/90L/4
PSH-43B/90L/4
PSH-4/90L/4
PSH-33/90L/4
PSH-33/90L/4
PSH-3/90L/4
PSH-3/90L/4
PSH-3/90L/4
PSH-3/90L/4
PSH-2/90L/4
PSH-2/90L/4
PSH-2/90L/4
PSH-2/90L/4

1.2
1.5
1.25
1.5
1.0
1.1
1.3
1.0
1.0
1.2
1.4
1.4
1.1
1.2
1.5

71.5
64.4
51.5
40.2
32.2
23.8
19.8
16.9
13.2
10.1
9.1
6.6
4.9
4.4
3.6

2.2 / 3.0

18
20
32
40
50
65
81
93
120
156
205
273
308
355

PSH-6/100L/8
PSH-53/100L/4
PSH-53/100L/4
PSH-43B/100L/4
PSH-43/100L/4
PSH-4/100L/4
PSH-4/100L/4
PSH-4/100L/4
PSH-4/100L/4
PSH-32/100L/4
PSH-32/100L/4
PSH-32/100L/4
PSH-32/100L/4
PSH-32/100L/4

1.3
1.0
1.5
1.3
1.1
1.1
1.4
1.2
1.7
2.4
2.6
2.0
2.2
2.5

107.3
96.6
60.4
48.3
38.6
29.7
23.8
20.7
16.1
12.3
9.4
7.0
6.2
5.4

3.7 / 5.0

18
20
25
31
40
57
68
85
95
120
156
205
273
308
355

PSH-7/132M/8
PSH-63/112M/4
PSH-63/112M/4
PSH-6/112M/4
PSH-53/112M/4
PSH-53/112M/4
PSH-43B/112M/4
PSH-43B/112M/4
PSH-42B/112M/4
PSH-42B/112M/4
PSH-4/112M/4
PSH-4/112M/4
PSH-4/112M/4
PSH-4/112M/4
PSH-4/112M/4

1.2
1.0
1.3
1.2
1.2
1.6
1.4
1.5
1.0
1.4
1.3
1.5
1.2
1.45
1.5

178.0
161.1
128.8
103.9
80.5
56.5
47.3
37.9
33.9
26.8
20.6
15.7
11.8
10.4
9.0

5.5 / 7.5

18
20
25
32
40
50
63
80
100
125
160
200
250
315
355

PSH-83/132S/4
PSH-83/132S/4
PSH-83/132S/4
PSH-63/132S/4
PSH-63/132S/4
PSH-63/132S/4
PSH-53/132S/4
PSH-53/132S/4
PSH-5/132S/4
PSH-5/132S/4
PSH-5/132S/4
PSH-5/132S/4
PSH-5/132S/4
PSH-5/132S/4
PSH-5/132S/4

1.5
1.7
2.1
1.0
1.4
1.6
1.25
1.6
1.0
1.2
1.6
1.9
1.3
1.7
1.8

268.5
241.6
193.3
151.0
120.8
96.6
76.7
60.4
48.3
38.6
30.2
24.1
19.3
15.3
13.6

7.5 / 10.0

18
20
25
32
40
50
63
80
100
125
160
200
250
315
355

PSH-83/132M/4
PSH-83/132M4
PSH-83/132M/4
PSH-7/132M/4
PSH-63/132M/4
PSH-63/132M/4
PSH-63/132M/4
PSH-6/132M/4
PSH-6/132M/4
PSH-6/132M/4
PSH-6/132M/4
PSH-6/132M/4
PSH-5/132M/4
PSH-5/132M/4
PSH-5/132M/4

1.2
1.3
1.6
1.1
1.0
1.5
1.5
1.5
1.4
1.1
1.5
1.7
1.0
1.3
1.4

357.9
322.2
257.7
201.3
161.1
128.8
102.0
80.5
64.6
51.5
40.2
32.2
25.7
20.4
18.1

9.3 / 12.5

20
25
28
32
40
50
63
80
100
125
160
200
250
315
355

PSH-83/160M/4
PSH-83/160M4
PSH-83/160M/4
PSH-83/160M/4
PSH-7/160M/4
PSH-7/160M/4
PSH-63/160M/4
PSH-63/160M/4
PSH-62/160M/4
PSH-62/160M/4
PSH-6/160M/4
PSH-6/160M/4
PSH-6/160M/4
PSH-6/160M/4
PSH-6/160M/4

1.0
1.3
1.4
1.6
1.1
1.3
1.25
1.5
1.1
1.5
1.2
1.4
1.0
1.3
1.7

403
322
288
252
201
161
128
101
80.5
64.4
50.3
40.2
32.2
25.5
22.6

11.0 / 15.0

28
32
40
50
63
80
100
125
160
200
250
315
355

PSH-83/160M/4
PSH-83/160M/4
PSH-83/160M/4
PSH-73/160M/4
PSH-7/160M/4
PSH-7/160M/4
PSH-7/160M/4
PSH-62/160M/4
PSH-62/160M/4
PSH-62/160M/4
PSH-62/160M/4
PSH-62/160M/4
PSH-62/160M/4

1.2
1.3
1.65
1.3
1.4
1.3
1.7
1.25
1.5
1.9
1.3
1.0
1.75

345.2
302.0
242.0
193.3
153.4
121.0
97.0
77.3
60.4
48.3
38.6
30.6
27.2

15.0 / 20.0

40
50
63
80
100
125
160
200
250
315
355

PSH-83/160L/4
PSH-83/160L/4
PSH-83/160L/4
PSH-7/160L/4
PSH-7/160L/4
PSH-7/160L/4
PSH-7/160L/4
PSH-62/160L/4
PSH-7/160L/4
PSH-7/160L/4
PSH-62/160L/4

1.25
1.35
1.7
1.35
1.3
1.65
2.0
1.4
1.7
2.0
1.4

322.2
258.0
204.5
161.0
128.8
103.0
80.5
64.4
51.5
40.9
36.3

18.5 / 25.0

56
63
71
80
100
125
160
200
250
315
355

PSH-83/180M/4
PSH-83/180M/4
PSH-83/180M/4
PSH-73/180M/4
PSH-73/180M/4
PSH-73/180M/4
PSH-7/180M/4
PSH-7/180M/4
PSH-7/180M/4
PSH-7/180M/4
PSH-7/180M/4

1.2
1.35
1.5
1.2
1.7
1.6
1.65
2.0
1.3
1.65
1.8

288
256
227
201.3
161.1
128.8
100.6
80.5
64.4
51.1
45.3

22.5 / 30.0

71
80
100
125
160
200
250
315
355

PSH-83/180L/4
PSH-83/180L/4
PSH-82/180L/4
PSH-82/180L/4
PSH-72/180L/4
PSH-7/180L/4
PSH-7/180L/4
PSH-7/180L/4
PSH-7/180L/4

1.25
1.4
1.1
1.45
1.0
1.6
1.1
1.35
1.6

272
241.6
193.3
154.6
120.8
96.6
77.3
61.3
54.4
